MD DK 250/1000 |
Airtronic / Standard |
Inter-roll Drive (belt retrofit) |
Synchronous + Poly-V (Hybrid - one side sync, one side ribbed) |
1760 |
8 |
220 |
PK 12 ribs |
57.2 |
|
MD DK 250/1000 |
Airtronic / Standard |
Inter-roll Drive (belt retrofit - Wide) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 36 ribs |
128.2 |
|
MD DK 250/1250 |
Airtronic / Standard |
Inter-roll Drive (belt retrofit) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 38 ribs |
135.3 |
|
MD DK 250/1000 |
Airtronic / Standard |
Main Motor Drive (V-belt to roller) |
Metric Wedge V-Belt SPB section |
2240 |
-- |
-- |
17 mm top width |
17.0 |
|
MD DL 250/1000 |
Standard / Gear or Belt |
Inter-roll Drive (belt drive version) |
Synchronous + Poly-V (Hybrid) |
1552 |
8 |
194 |
PK 16 ribs |
60.1 |
|
MD DL 250/1000 |
Standard / Gear or Belt |
Inter-roll Drive (belt drive - Wide) |
Synchronous + Poly-V (Hybrid) |
1552 |
8 |
194 |
PK 32 ribs |
113.9 |
|
MD DL 250/1250 |
Standard / Gear or Belt |
Inter-roll Drive (belt drive - Wide) |
Synchronous + Poly-V (Hybrid) |
1552 |
8 |
194 |
PK 36 ribs |
128.2 |
|
MD DL 250/1000 |
Standard |
Inter-roll Drive (S8M / STPD sprocket) |
Synchronous + Poly-V (S-profile Hybrid) |
1552 |
8 |
194 |
PK 30 ribs |
106.8 |
|
MD DP 250/600 |
Dolomit (current gen) |
Inter-roll Drive (belt transmission) |
Synchronous + Poly-V (Hybrid) |
1552 |
8 |
194 |
PK 12 ribs |
42.7 |
|
MD DP 250/1000 |
Dolomit (current gen) |
Inter-roll Drive (belt transmission) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 12 ribs |
42.7 |
|
MD DP 250/1250 |
Dolomit (current gen) |
Inter-roll Drive (belt transmission) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 20 ribs |
71.2 |
|
MD DP 250/1500 |
Dolomit (current gen) |
Inter-roll Drive (belt transmission) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 24 ribs |
85.4 |
|
MD DP 300/1000 |
Dolomit (current gen) |
Inter-roll Drive (14M belt - 300mm roll dia ) |
Synchronous + Poly-V (14M) |
1778 |
14 |
127 |
PK 12 ribs |
57.2 |
|
MD DP 300/1250 |
Dolomit (current gen) |
Inter-roll Drive (14M belt - 300mm roll dia ) |
Synchronous + Poly-V (14M) |
1778 |
14 |
127 |
PK 36 ribs |
128.2 |
|
MD DQ 250/1000 |
Dolomit 8-roller |
Inter-roll Drive (belt transmission - each pair) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 12 ribs |
42.7 |
|
MD DQ 250/1250 |
Dolomit 8-roller |
Inter-roll Drive (belt transmission - each pair) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 18 ribs |
64.1 |
|
MD DY 250/1000 |
Diorit (current gen) |
Inter-roll Drive (belt transmission) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 12 ribs |
42.7 |
|
MD DY 300/1000 |
Diorit (current gen) |
Inter-roll Drive (14M belt - 300mm roll dia) |
Synchronous + Poly-V (14M) |
1778 |
14 |
127 |
PK 12 ribs |
57.2 |
|
MD DZ 250/1000 |
Diorit 8-roller |
Inter-roll Drive (per pair of rolls) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 12 ribs |
42.7 |
|
MD DO 250/1000 |
Older / Transition |
Inter-roll Drive (belt or gear) |
Synchronous + Poly-V (Hybrid) |
1552 |
8 |
194 |
PK 16 ribs |
60.1 |
|
MD DM 250/1000 |
Newtronic / Standard |
Inter-roll Drive (belt drive) |
Synchronous + Poly-V (Hybrid) |
1760 |
8 |
220 |
PK 12 ribs |
42.7 |
|
MD DB 250/1000 |
Older B-series |
Inter-roll Drive (dual-sided V-ribbed) |
Dual-Sided Poly-V (PVL both sides) |
1765 |
-- |
-- |
22 ribs |
78.3 |
|
MD DB 250/1000 |
Older B-series |
Inter-roll Drive (dual-sided V-ribbed - wide) |
Dual-Sided Poly-V (PVL both sides) |
1765 |
-- |
-- |
26 ribs |
92.5 |
|
MD DP / MD DY Large Capacity |
Dolomit / Diorit 1500mm+ roll |
Inter-roll Drive (extended pitch length) |
Synchronous + Poly - V (Hybrid - 2400 series) |
2400 |
8 |
300 |
PK 12 ribs |
42.7 |
|
MD DP / MD DY Large Capacity |
Dolomit / Diorit 1500mm+ roll |
Inter-roll Drive (extended pitch - wide) |
Synchronous + Poly - V (Hybrid - 2400 series) |
2400 |
8 |
300 |
PK 36 ribs |
128.2 |
|
MD DP / MD DY 2800 Series |
Special / Extra-Large |
Inter-roll Drive (2800mm pitch length) |
Synchronous + Poly - V (Hybrid - 2800 series) |
2800 |
8 |
350 |
PK 16 ribs |
60.1 |
